Monday, 27 March 2017

uBITX




Ashar Farhan has developped a compact HF transceiver with following characteristics:

- 10 Watts PEP on lower HF bands
- SSB and CW
- Minimal controls
- Based on Arduino controller and one Si5351 for all local oscillators
- Double conversion, high IF superhet architecture
- Easy to build, low priced components used


Enjoy his article: http://www.phonestack.com/farhan/ubitx/ubitx.html

And the interview

Friday, 24 March 2017

USB Microscope

In order to be able to do visual inspections of PCB’s or components I normally use a magnifier glass. Where the magnifier glass offers a magnification of 5X, a low-cost USB microscope can give you 20..500X.
The USB microscope I ordered for about 15 euro gives interesting results. It contains 8 white LEDs that illuminate the object to be investigated from above. The focus range and magnification can be adjusted.  LED Light intensity can be changed. It really turned out to be a plug-and-play device. Plug in the USB connector, install the software and enjoy the pictures (and even moving images). Great fun.

USB Microscope set-up and PCB:







Dove's feather




5 cents Euro coin



 Sanding paper


 30 pF capacitor





http://www.banggood.com/New-USB-8-LED-500X-2MP-Digital-Microscope-Endoscope-Magnifier-Video-Camera-with-Suction-Cup-Stand-p-1132026.html?rmmds=search
